Drolet Escape 1500 Wood Stove

Escape 1500 Wood Stove by Drolet

Always looking for the best on the market?  The Drolet Escape 1500 Wood Stove (DB03135) is the obvious choice! Combining performance and eco-friendliness in a compact device, it largely meets EPA's new standards with an incredibly low average particle emission rate; 1.26 g/h despite a heat output of 65,000 BTU/h.

Offered on a pedestal with a black door, this model is perfect for an alcove as well as a mobile home installation.  The unit is equipped with side panels which help reduce clearances to combustible materials and a top heat exchanger which redirects heat to the front of the unit.

To meet your needs, a blower, a thermodisc, a firescreen, and a fresh air intake kit are available as options.

Features

• Optimum efficiency: 78 %
• Average particulate emissions rate: 1.26 g/h
• High-efficiency certified appliance: Yes, EPA 2020 approved
• Firebox lined with refractory bricks for better heat distribution
• Recommended heating area-ft² : 500 - 1,800
• Approved for a mobile home installation
• Steel thickness – top: 5/16"

Specifications

• Burn time up to 6 hours
• Up to 18'' logs
• 1.9 ft³ firebox
• Overall dimension (Height) 29 7/8"
• Overall dimension (Width) 24 7/8"
• Overall dimension (Depth) 24 1/2"




Included Accessories

• pedestal with ash drawer, airmate, ceramic glass, side panels, ash lip, air damper

Optional Add-Ons

• blower, thermodisc, firescreen, fresh air intake



Get a Federal Tax Credit on Your Purchase

Did you know that you can claim a U.S. federal tax credit of 30% on your federal tax return for this purchase?

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

Click here to Learn More

Click here to download Drolet's Tax Credit Certificate



Appliance Performance

⁽¹⁾ This appliance is officially tested and certified by an independent agency.

⁽²⁾ Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

⁽⁾ Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

⁽³⁾ The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³ and reloading intervals ranging from 60 to 120 minutes. Other performances are based on a fuel load prescribed by the standard without any reloading between start and finish. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

⁽⁴⁾ As measured per CSA B415.1-10 stack loss method.

⁽⁵⁾ Higher Heating Value of the fuel.

⁽⁶⁾ Lower Heating Value of the fuel.

⁽⁷⁾ Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

⁽⁸⁾ Optimum overall efficiency at a specific burn rate (LHV).

⁽⁹⁾ The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the wood logs into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.

⁽¹⁰⁾ Carbon monoxyde.

General Features

Combustion technology	Non-catalytic
High-efficiency certified appliance	Yes, EPA 2020 approved
Maximum log length	18"
Log positioning	Loading over width
Chimney diameter	6"
Flue outlet diameter	6"
Type of chimney	CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet)	12'
Baffle type	High quality vermiculite
Approved for an alcove installation	Yes
Approved for a mobile home installation	Yes, with fresh air intake
Shipping Weight	332 lb (151 kg)
Door type	Single, glass with cast iron frame
Glass type	Ceramic glass
Glass surface – dimensions (Width X Height)	15 3/4" x 9 3/4"
Glass air-wash system	Yes
Overall dimension (Height)	29 7/8"
Overall dimension (Width)	24 7/8"
Overall dimension (Depth)	24 1/2"
Door opening – dimension (Height)	8"
Door opening - dimension (Width)	17 1/4"
Firebox – dimension (Height)	11 7/8"
Firebox – dimension (Width)	19 5/8"
Firebox – dimension (Depth)	13 1/2"
Firebox lined with refractory bricks for better heat distribution	Yes
Stainless-steel secondary-air system improving gas combustion	Yes
Model	Pedestal
Steel thickness – body	3/16"
Steel thickness – top	5/16"
USA standard (emissions)	EPA
Canadian Standard (emissions)	CSA B415.1-10
USA standard (safety)	UL 1482, UL 737
Canadian standard (safety)	ULC S627
Tested and listed as per applicable standards	By an accredited laboratory (CAN/USA)
Warranty	Limited lifetime



Minimum clearances to combustibles* (Data expressed in inches. 1 inch = 25.4 mm)
	Canada		United-States
	Single wall pipe	Double wall pipe	Single wall pipe	Double wall pipe
Clearance – back wall	14 1/2"	6"	13"	6"
Clearance - corner	12"	12"	12"	12"
Clearance – side wall	10"	10"	10"	10"
Clearance – top (measured from the platform on which the appliance is installed)**	84"	84"	84"	84"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or websites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.

Warranty

All Drolet products come with a Limited Manufacturer's Warranty. Depending on which part of the Wood Stove; Drolet offers a 1 Year -LifeTime warranty. It covers any problem with the product that affects its function. Please register your warranty on our brand's warranty registration page.



Installation and Operation Manual



Appliance Dimensions
