Drolet Escape 1800 Wood Stove With Black Door
Drolet Escape 1800 Wood Stove With Black Door
Escape 1800 Wood Stove With Black Door by Drolet
Dimensions: 17 1/2" L x 12" W x 4 3/4" H
- Flexible positioning for ideal fit
- Enhances heat and combustion
- Durable and easy to clean
- Maximizes firewood burning efficiency
- Supports logs for stable burning
- Prevents logs from rolling or shifting
- Increases overall fireplace safety
- Helps maintain consistent heat output
Description
Looking for a high-efficiency wood stove, EPA 2020 certified at a fair price? The Drolet Escape 1800 Wood Stove with Black Door (DB03102) is the perfect device with an incredibly low particulate emissions rate of only 1.54 g/h. Ideal for spaces up to 2,100 ft², this large non-catalytic wood stove produces up to 75,000 BTU/h.
This pedestal model is an east-west loader that accepts logs up to 20 inches long. It comes with a top heat exchanger that allows the user to maximize the benefits of its optional blower. Its very low clearances to combustible materials make it a safe bet in the Large wood stoves category.
Features
- Optimum efficiency: 77 %
- Average particulate emissions rate: 1.54 g/h
- High-efficiency certified appliance: Yes, EPA 2020 approved
- Firebox lined with refractory bricks for better heat distribution
- Recommended heating area-ft² : 500 - 2,100
- Approved for a mobile home installation
- Easy-to-access ash drawer
- Steel thickness – top: 5/16"
Specifications
- Up to 8 hours burn time
- Up to 20'' logs
- 2.4 ft³ firebox
- Overall dimension (Height) 32 5/8"
- Overall dimension (Width) 25 5/8"
- Overall dimension (Depth) 25 3/4"
Included Accessories
- pedestal with ash drawer, top air deflector, ceramic glass, side panels, ash lip, air damper
Optional Add-Ons
- Firescreen
- Fresh Air Intake Kit
- Flex Pipe For Fresh Air Intake Kit
- Fresh Air Intake Register With Airtight Damper
Get a Federal Tax Credit on Your Purchase
Did you know that you can claim a U.S. federal tax credit of 30% on your federal tax return for this purchase?
*Any installation must be done according to the data and drawings detailed in the owner’s manual.
Click here to download Drolet's Tax Credit Certificate
Appliance Performance
(1) This appliance is officially tested and certified by an independent agency.
(2) Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.
() Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.
(3) The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³ and reloading intervals ranging from 60 to 120 minutes. Other performances are based on a fuel load prescribed by the standard without any reloading between start and finish. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.
(4) As measured per CSA B415.1-10 stack loss method.
(5) Higher Heating Value of the fuel.
(6) Lower Heating Value of the fuel.
(7) Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.
(8) Optimum overall efficiency at a specific burn rate (LHV).
(9) The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the wood logs into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.
(10) Carbon monoxyde.
General Features
| Combustion technology | Non-catalytic |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 20" |
| Log positioning | Loading over width |
| Chimney diameter | 6" |
| Flue outlet diameter | 6" |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height (feet) | 12' |
| Baffle type | High quality vermiculite |
| Approved for an alcove installation | Yes |
| Approved for a mobile home installation | Yes, with fresh air intake |
| Shipping Weight | 382 lb (173 kg) |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 16" X 9 1/4" |
| Glass air-wash system | Yes |
| Overall dimension (Height) | 32 5/8" |
| Overall dimension (Width) | 25 5/8" |
| Overall dimension (Depth) | 25 3/4" |
| Door opening – dimension (Height) | 9" |
| Door opening - dimension (Width) | 17 1/2" |
| Firebox – dimension (Height) | 12" |
| Firebox – dimension (Width) | 21" |
| Firebox – dimension (Depth) | 16 1/2" |
| Firebox lined with refractory bricks for better heat distribution | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Model | Pedestal |
| Steel thickness – body | 3/16" |
| Steel thickness – top | 5/16" |
| Easy-to-access ash drawer | Yes |
| USA standard (emissions) | EPA / ASTM WK47329 |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S627 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
| Minimum clearances to combustibles* (Data expressed in inches. 1 inch = 25.4 mm) | ||||
| Canada | United-States | |||
| Single wall pipe | Double wall pipe | Single wall pipe | Double wall pipe | |
| Clearance – back wall | 14 1/2" | 6" | 11" | 6" |
| Clearance - corner | 10" | 7" | 10" | 7" |
| Clearance – side wall | 17" | 17" | 16" | 16" |
| Clearance – top (measured from the platform on which the appliance is installed)** | 84" | 84" | 84" | 84" |
* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).
** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.
Warranty
All Drolet products come with a Limited Manufacturer's Warranty. Depending on which part of the Wood Stove; Drolet offers a 1 Year -LifeTime warranty. It covers any problem with the product that affects its function. Please register your warranty on our brand's warranty registration page.
