Drolet Escape 1800 Wood Stove On Legs - Black Door

Dimensions: 17 1/2" L x 12" W x 4 3/4" H

• Flexible positioning for ideal fit
• Enhances heat and combustion
• Durable and easy to clean
• Maximizes firewood burning efficiency
• Supports logs for stable burning

• Prevents logs from rolling or shifting
• Increases overall fireplace safety
• Helps maintain consistent heat output

Looking for a high-efficiency wood stove, EPA 2020 certified at a fair price? The Escape 1800 is ideal for spaces up to 2,100 ft². This large non-catalytic wood stove produces up to 75,000 BTU/h the perfect device with an incredibly low particulate emissions rate of only 1.54 g/h of fine particles.

This black-leg model is an east-west loader that accepts logs up to 20 inches long. It comes with a top heat exchanger that redirects the heat to the front of the unit and allows the user to clearly maximize the benefits of its optional blower.

Its black door gives it a touch of sobriety. The unit is equipped with side panels that reduce clearances to combustible materials making it a safe bet in the large wood stoves category.

• Optimum efficiency: 77 %
• Average particulate emissions rate: 1.54 g/h
• High-efficiency certified appliance: Yes, EPA 2020 approved
• Firebox lined with refractory bricks for better heat distribution
• Recommended heating area-ft² : 500 - 2,100
• Approved for a mobile home installation
• Easy-to-access ash drawer
• Steel thickness – top: 5/16"

Specifications

• Up to 8 hours burn time
• Up to 20'' logs
• 2.4 ft³ firebox
• Overall dimension (Height) 30 1/4"
• Overall dimension (Width) 26 1/8"
• Overall dimension (Depth) 25 7/8"
• Weight : 375 lbs




Included Accessories

• cast iron legs with ash drawer, top air deflector, ceramic glass, side panels, ash lip, air damper

Optional Add-Ons

• Firescreen
• Fresh Air Intake Kit
• Flex Pipe For Fresh Air Intake Kit
• Fresh Air Intake Register With Airtight Damper
• Thermodisc Kit
• Blower Assembly With Variable Speed Control
• 10mm Glass Hearth Pad
• 25' Vortex Stainless Flex Liner Kit
• 35' Vortex Stainless Flex Liner Kit

Get a Federal Tax Credit on Your Purchase

Did you know that you can claim a U.S. federal tax credit of 30% on your federal tax return for this purchase?

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

Click here to Learn More

Click here to download Drolet's Tax Credit Certificate



Appliance Performance

⁽¹⁾ This appliance is officially tested and certified by an independent agency.

⁽²⁾ Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

⁽⁾ Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type and other variables. The recommended heated area for a given appliance is defined by the manufacturer as its capacity to maintain a minimum acceptable temperature in the designated area in case of a power failure.

⁽³⁾ The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft³ and 20 lb/ft³ and reloading intervals ranging from 60 to 120 minutes. Other performances are based on a fuel load prescribed by the standard without any reloading between start and finish. The specified loading density varies between 7 lb/ft³ and 12 lb/ft³. The moisture content is between 19% and 25%.

⁽⁴⁾ As measured per CSA B415.1-10 stack loss method.

⁽⁵⁾ Higher Heating Value of the fuel.

⁽⁶⁾ Lower Heating Value of the fuel.

⁽⁷⁾ Performances based on a fuel load prescribed by the standard at 7 lb/ft³ and with a moisture content between 19% and 25%.

⁽⁸⁾ Optimum overall efficiency at a specific burn rate (LHV).

⁽⁹⁾ The optimum heat transfer efficiency is for the low burn rate (using HHV) and represents the appliance’s ability to convert the energy contained in the wood logs into energy transferred to the room in the form of heat and does not take into account the chemical losses during combustion.

⁽¹⁰⁾ Carbon monoxyde.

General Features

Combustion technology	Non-catalytic
High-efficiency certified appliance	Yes, EPA 2020 approved
Maximum log length	20"
Log positioning	Loading over width
Chimney diameter	6"
Flue outlet diameter	6"
Type of chimney	CAN/ULC S629, UL 103 HT (2100 °F)
Minimum chimney height (feet)	12'
Baffle type	High quality vermiculite
Approved for an alcove installation	Yes
Approved for a mobile home installation	Yes, with fresh air intake
Shipping Weight	382 lb (173 kg)
Door type	Single, glass with cast iron frame
Glass type	Ceramic glass
Glass surface – dimensions (Width X Height)	16" X 9 1/4"
Glass air-wash system	Yes
Overall dimension (Height)	32 5/8"
Overall dimension (Width)	25 5/8"
Overall dimension (Depth)	25 3/4"
Door opening – dimension (Height)	9"
Door opening - dimension (Width)	17 1/2"
Firebox – dimension (Height)	12"
Firebox – dimension (Width)	21"
Firebox – dimension (Depth)	16 1/2"
Firebox lined with refractory bricks for better heat distribution	Yes
Stainless-steel secondary-air system improving gas combustion	Yes
Model	Pedestal
Steel thickness – body	3/16"
Steel thickness – top	5/16"
Easy-to-access ash drawer	Yes
USA standard (emissions)	EPA / ASTM WK47329
Canadian Standard (emissions)	CSA B415.1-10
USA standard (safety)	UL 1482, UL 737
Canadian standard (safety)	ULC S627
Tested and listed as per applicable standards	By an accredited laboratory (CAN/USA)
Warranty	Limited lifetime



Minimum clearances to combustibles* (Data expressed in inches. 1 inch = 25.4 mm)
	Canada		United-States
	Single wall pipe	Double wall pipe	Single wall pipe	Double wall pipe
Clearance – back wall	14 1/2"	6"	11"	6"
Clearance - corner	10"	7"	10"	7"
Clearance – side wall	17"	17"	16"	16"
Clearance – top (measured from the platform on which the appliance is installed)**	84"	84"	84"	84"

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

** Some appliances have been tested with a low ceiling. Before setting up your unit, refer to the installation manual.

Warranty

All Drolet products come with a Limited Manufacturer's Warranty. Depending on which part of the Wood Stove; Drolet offers a 1 Year -LifeTime warranty. It covers any problem with the product that affects its function. Please register your warranty on our brand's warranty registration page.
